MEDS-5210
NVIDIA® Jetson AGX Orin SOM; 32GB/64GB LPDDR5; 64GB eMMC, M.2 (NVMe SSD); 1GbE, 10GbE; HDMI® ; USB 3.2 TypeA, USB 3.2 Type C; PCIe Gen4x8; M.2 (WiFi/BT); Isolated Serial ports; GMSL2 Camera (Optional)
- Medical Edge AI Box PC with NVIDIA ® Jetson AGX Orin
- 32GB/64GB 256-bit LPDDR5 (from SOM)
- 1x 64GB eMMC (from SOM), 1x M.2 M-Key NVMe (PCIe x4)
- 1x 1GbE & 1x 10GbE; 1x M.2 E-key for WiFi/BT Module (WiFi 6E Supported) 6x USB 3.2 Type-A, 2x USB 3.2 Type-C on front side
- 4x Fakra-Z (GMSL2 Camera, Optional) or 1x 120-pin Samtec MIPI CSI-2 Connector, 1 x PCIe Gen4 x8 Slot Expansion (ext. Video Capture Card for 3G/12G-SDI)
specifications
Detailed Technical Specifications
Explore the complete technical specifications, available configurations and key features to determine whether this platform meets the requirements of your application.
| Sys Form Factor | Proprietary |
|---|---|
| Processor | NVIDIA ® Jetson AGX Orin™ 32G (8-core NVIDIA Arm ® Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3) NVIDIA ® Jetson AGX Orin™ 64G (12-core NVIDIA Arm ® Cortex A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3) |
| Memory | Support up to 64GB 256-bit LPDDR5 on board |
| Storage | 1 x M.2 Key-M NVMe PCIe x4 22801 x eMMC 64G on board |
| Graphic Controller | NVIDIA ® Ampere ® GPU 1792 NVIDIA CUDA cores and 56 Tensor ensorcores Ray-Tracing cores, NVIDIA ® Ampere ® GPU 2048 NVIDIA CUDA cores and 64 Tensorcores Ray-Tracing cores |
| Audio | 1 x Audio Jack Line-out on Front1 x Audio Jack Mic-in on Front |
| Ethernet | 1 x GbE1 x 10 GbE |
| Serial Port | 2 x Isolated DB9 COM Ports Support RS-232/422/485 |
| USB | 6 x USB 3.2 Gen1 Type A on Front2 x USB 3.2 Gen1 Type C on Front |
| GPIO | 1 x 8-bit Digital I/Os on Board Pin Header |
| Display | 1 x HDMI ® 2.14096 x 2160@60Hz |
| Other | Power Button with LED Indicater on Front, Reset Button on Front, Recovery Button on Board, JTAG Header on Board, RTC battery on Board, Grounding Stud |
| Antenna | 2 x SMA Antenna holes for Wi-Fi / BT |
| Video Input | 4 x Fakra-Z GMSL2 Camera (Optional) |
| PCIe | 1 x slot with PCIe x8 PCIe x4 |
| Ethernet | 1 x 1 GbE Lan1 x 1 x10 GbE Lan |
| M.2 | 1 x E Key w/ 2230 PCIe x1 and USB 2.0 for WiFi/BT module |
| Power Supply | 4Pin-DIN Jack 19V |
| Dimension (WxDxH) | 235 x188 x 120 mm (9.25" x 7.40" x 4.72" ) |
| Weight | 3.5 kg |
| Mounting | Desktop |
| Cooling | CPU1 x Cooler System1 x Fan |
| Power Supply | DC Jack 19V with 150W Medical-grade power adapter |
| Operating Temperature | 0 ~ 40 °C (32.0 ~ 104.0 °F) |
| Storage Temperature | -40 ~ 80 °C (-40.0 ~ 176.0 °F) |
| BSP | 6.2 |
| OS | Linux (NVIDIA JetPack OS) |
