- Engicam
MicroGEA STM32MP2
Interactive view and technical overview of the product.
specifications
Detailed Technical Specifications
Explore the complete technical specifications, available configurations and key features to determine whether this platform meets the requirements of your application.
| CPU | STM32MP2x |
|---|---|
| CPU #2 | Manufacturer: ST |
| CPU #3 | NPU: ja |
| CPU #4 | GPU: ja |
| Cores | ARM |
| Cores #2 | Single or dual core Arm® Cortex-A35 @1.5 GHz and Arm® Cortex-M33@400MHz |
| Memory | LPDDR4@2400MTs |
| Memory #2 | 1GB up to 2GB |
| Graphics & AI | 3D GPU and NPU: VeriSilicon® GC8000UL Up to 900 MHz TensorFlowLite - ONNX - Linux NN OpenGL® ES 3.2.8 – Vulkan 1.2 OpenCL™ 3.0, OpenVX™ 1.3 Up to 150 Mtriangle/s, 900 Mpixel/s |
| Video Processing Unit Capabilities | 1080p60 HEVC (h.264, VP8) dec 1080p60 HEVC (h.264, VP8) enc |
| Mass Storage | Starting from 8 GB, soldered on-board |
| Networking | 1x 10/100 Ethernet |
| USB | 2x USB2 |
| PCIe | NO |
| Audio | I2S interface |
| Peripheral Interfaces | UART, I2C, SPI, CAN Bus, PWM, SDIO i/f, JTAG i/f, GPIOs |
| Power Supply | single 5V |
| Operating Temperature | -25° up to 85° |
| Dimensions | 25 x 25 mm |
| Product availability | 2036 |
downloads
Documents & Downloads
| Title | Size | Download |
|---|---|---|
| MicroGea_STM32MP2_Flyer.pdf | 240.87 KB | download – MicroGea_STM32MP2_Flyer.pdf |
