Nano-ITX Embedded Boards

About Nano-ITX Embedded Boards

Compact 120 × 120 mm Platforms for Space-Constrained Systems Portwell Nano-ITX embedded boards integrate processing, display, networking, storage and peripheral connectivity within the compact 120 × 120 mm form factor. Based on selected Intel® low-power processor platforms, these boards support space-constrained industrial controllers, embedded displays, IoT gateways and other compact system designs. Standard 120 × 120 mm Nano-ITX form factor Selected Intel® Atom® and low-power Intel processor platforms DDR5 and previous-generation memory options depending on the selected model Dual- or triple-display configurations on selected models HDMI®, DisplayPort, LVDS and eDP display options Gigabit Ethernet or 2.5GbE connectivity depending on the selected board USB, SATA, M.2, Mini PCI Express and mSATA options TPM 2.0 security support on selected models Selecting a Nano-ITX Board for Compact Systems When selecting a Nano-ITX embedded board, evaluate the processor performance, memory capacity, display configuration, network speed and storage interfaces required by the application. Expansion space is more limited than on larger motherboard form factors, so the availability and placement of onboard connectors should be confirmed during the enclosure and system design stages. For compact or fanless systems, also review processor power, cooling requirements, operating temperature and airflow within the enclosure. Interface availability varies by model; refer to the individual product specifications to confirm display outputs, expansion slots, storage support and security features.
